Main Distribution Box with 1 x Power Lock Set 500A Input and 400A Main MCCB, 2 x 125A 400V 5P, 4 x 63A 400V 5P, 6 x 32A 400V 5P, 6 x 16A 240V 3P and 1 x Power Lock Set 500A Outputs – MCB Protection
MD400-361MCB
INPUT | |
---|---|
Plugs | Breakers |
5 x Power Lock Set 500A Single Pole 3 Phase | 5 x 400A Main MCCB 4P |
OUTPUT | |
---|---|
Sockets | Breakers |
5 x Power Lock Set 500A Single Pole 3 Phase | No Breakers |
6 x PCE 16A CEE 240V 3 Pin Socket | 6 x 16A MCB 1P |
6 x PCE 32A CEE 400V 5 Pin Socket | 6 x 32A MCB 4P |
4 x PCE 63A CEE 400V 5 Pin Socket | 4 x 63A MCB 4P |
2 x PCE 125A CEE 400V 5 Pin Socket | 2 x 125A MCB 4P |
CASE |
---|
20U Flight Case |
FEATURES | Digital Multimeter: 1 x Digital Multimeter measures Amps, Volts & Frequency Pilot LED Lights: 3 x Red, 1 x Blue, 1 x Green Protection Level: MCB Additional Information: Made of Premium Components. |
---|
