Main Distribution Box with 1 x 63A CEE 400V 5P Input, 3 x 19 Pin Connector, 6 x 16A CEE 240V 3P, 1 x 32A CEE 400V 5P Outputs – RCD and MCB Protection
MD63-013RCD
| INPUT | |
|---|---|
| Plugs | Breakers |
1 x PCE 63A CEE 400V 5 Pin Plug | 1 x 63A MCB 4P |
| OUTPUT | |
|---|---|
| Sockets | Breakers |
2 x 19 Pin Socket Connector | 2 x 40A RCD 4P |
6 x PCE 16A CEE 240V 3 Pin Socket | 1 x 40A RCD 4P |
1 x PCE 32A CEE 400V 5 Pin Socket | 1 x 32A MCB 4P |
| CASE |
|---|
8U High-density Polyethylene Case 610x580x600mm |
| FEATURES | Digital Multimeter: 1 x Digital Multimeter measures Amps, Volts & Frequency Pilot LED Lights: 3 x Red, 1 x Blue, 1 x Green Protection Level: RCD Additional Information: Made of Premium Components. |
|---|
