Main Distribution Box with 1 x 63A CEE 400V 5P Input, 3 x 16A CEE 240V 3P, 3 x 13A UK Type 240V, 4 x 16A CEE 400V 5P and 2 x 32A CEE 400V 5P Outputs – RCBO Protection
MD63-381RCBO
INPUT | |
---|---|
Plugs | Breakers |
1 x PCE 63A CEE 400V 5 Pin Plug | 1 x 63A MCB 4P |
OUTPUT | |
---|---|
Sockets | Breakers |
3 x PCE 16A CEE 240V 3 Pin Socket | 3 x 13A BS 3P |
4 x PCE 16A CEE 400V 5 Pin Socket | 4 x 16A MCB 4P |
2 x PCE 32A CEE 400V 5 Pin Socket | 2 x 32A MCB 4P |
CASE |
---|
12U High-density Polyethylene Case 610x580x764mm |
FEATURES | Pilot LED Lights: 3 x Red Protection Level: RCBO Additional Information: Made of Premium Components |
---|
