MD63-381RCBO

SKU: MD63-381RCBO CATEGORY:
Add to quote
INPUT
PlugsBreakers

1 x PCE 63A CEE 400V 5 Pin Plug

1 x 63A MCB 4P

OUTPUT
SocketsBreakers

3 x PCE 16A CEE 240V 3 Pin Socket
x

3 x 13A BS 3P
3 x 10A RCBO
3 x 16A RCBO

4 x PCE 16A CEE 400V 5 Pin Socket

4 x 16A MCB 4P

2 x PCE 32A CEE 400V 5 Pin Socket

2 x 32A MCB 4P

CASE

12U High-density Polyethylene Case 610x580x764mm
Stackable
Integrated Handles and Wheels
IP65 with lids closed

FEATURES

Pilot LED Lights: 3 x Red

Protection Level: RCBO

Additional Information: Made of Premium Components

Download MD63-381RCBO Technical Sheet

Add to quote

Main Distribution Box with 1 x 63A CEE 400V 5P Input, 3 x 16A CEE 240V 3P, 3 x 13A UK Type 240V, 4 x 16A CEE 400V 5P and 2 x 32A CEE 400V 5P Outputs – RCBO Protection
