MD63-421

RCD
63A Main Distribution Boxes
IN: 63A CEE 400V 5P Cable Plug
OUT: 16A CEE 240V 3P Cable Socket, 32A CEE 240V 3P Cable Socket, 32A CEE 400V 5P Cable Socket, 63A CEE 400V 5P Cable Socket, 63A CEE 240V 3P Cable Socket
  • MD63-421RCD

    MD63-421RCD

    SKU: MD63-421RCD CATEGORY:
    Learn more
    Add to quote
    INPUT
    PlugsBreakers

    1 x PCE 63A CEE 400V 5 Pin Plug

    1 x 63A MCB 4P

    OUTPUT
    SocketsBreakers

    9 x PCE 16A CEE 240V 3 Pin Socket

    1 x 63A RCD 4P
    9 x 16A MCB 1P

    6 x PCE 32A CEE 240V 3 Pin Socket

    1 x 63A RCD 4P
    6 x 32A MCB 1P

    4 x PCE 32A CEE 400V 5 Pin Socket

    4 x 40A RCD 4P
    4 x 32A MCB 4P

    1 x PCE 63A CEE 400V 5 Pin Socket

    1 x 63A RCD 4P
    1 x 63A MCB 4P

    1 x PCE 63A CEE 240V 3 Pin Socket

    1 x 63A RCD 2P
    1 x 63A MCB 1P

    CASE

    16U High-density Polyethylene Case 610x580x950mm
    Stackable
    Integrated Handles and Wheels
    IP65 with lids closed

    FEATURES

    Digital Multimeter: 1 x Digital Multimeter measures Amps, Volts & Frequency

    Pilot LED Lights: 3 x Red, 1 x Blue, 1 x Green

    Protection Level: RCD

    Additional Information: Made of Premium Components

    Download MD63-421RCD Technical Sheet
