Main Distribution Box with 1 x 125A CEE 400V 5P Input, 3 x 63A CEE 240V 3P, 3 x 125A CEE 240V 3P, 1 x 63A CEE 400V 5P and 1 x 125A CEE 400V 5P Through Outputs – RCD and MCB Protection
MD125-440RCD
| INPUT | |
|---|---|
| Plugs | Breakers |
1 x PCE 125A CEE 400V 5 Pin Plug | 1 x 125A MCB 4P |
| OUTPUT | |
|---|---|
| Sockets | Breakers |
1 x 125A 5P LOOP Through | No Breakers |
3 x PCE 63A CEE 240V 3 Pin Socket | 3 x 63A RCD 2P |
3 x 125A CEE 240V 3 Pin Flanged Socket | 3 x 100A MCB 2P |
1 x PCE 63A CEE 400V 5 Pin Socket | 1 x 63A MCB 4P |
| CASE |
|---|
16U High-density Polyethylene Case 610x580x950mm |
| FEATURES | Digital Multimeter: 1 x Digital Multimeter measures Amps, Volts & Frequency Pilot LED Lights: 3 x Red, 1 x Blue, 1 x Green Protection Level: RCD Additional Information: Made of Premium Components |
|---|
